Stereo Enclosed Speaker (3 W, 8 ohm)-CQR0508
Revision as of 09:54, 2 February 2018 by Yangguo (talk | contribs) (Created page with "thumb|300px|right|JST-PH2.0 interface Stereo Enclosed Speaker (2 PCS) 3 W 8 Ohm ==Introduction== CQRobot painstakingly deploys this passive speaker sm...")
Introduction
CQRobot painstakingly deploys this passive speaker small speaker for the Makers and electronic enthusiasts, this small passive speaker with JST PH2.0 interface, the internal resistance is 8 ohms, the power of it is 3 watts. Strip size, with mounting screw, suitable for all kinds of sound source fabrication, the sound is clear and melodious without distortion.
Features
- Applied to TV, Advertising machine,Integrated machine special speaker, Robot, DIY production and other projects.
- JST-PH2.0 interface passive speaker small horn, 3 watts power, 8 ohm impedance.
- Long size with the screw holes of installation, suitable for all kinds of sound source fabrication, the sound is clear and melodious without distortion.
APPLICATION
- TV
- Advertising machine
- Integrated machine special speaker
- Robot
- Raspberry Pi and Arduino DIY Projects
Parameters
Type | value |
---|---|
Magnetic Hugh | 12.5 * 2.0 |
Power | rated power / maximum power 2.0W / 3.0W |
Impedance | 8 Ohms Plus/Minus 15% |
Resonance frequency | 450 HZ Plus/Minus 120 HZ |
S.P.L | 86dB Plus/Minus 3 dB Ref 1.0W/0.5M |
Effectine freq band | Fo to 20 KHZ MAX:20 dB |
Screw hole distance | 24 * 63 mm |
Size | 70 * 31 * 15 MM |
Total weight | 24g |
Display
SHIPPING LIST
- 2 * Passive speaker
DOCUMENTS
